Box Name | Box SKU | Box QTY | Length | Width | Height | Weight |
T1416-IG-BOX-2946-2 | 2946-2 | 1 | 41 cm | 31 cm | 15 cm | 12.9 kg |
T1416-IG-BOX-2946-1 | 2946-1 | 1 | 41 cm | 31 cm | 15 cm | 12.9 kg |
T1416-IG-BOX-2945-A | 2945-A | 1 | 130 cm | 50 cm | 8 cm | 12 kg |
T1416-IG-BOX-2944 | 2944 | 1 | 284 cm | 32.5 cm | 20.5 cm | 74.3 kg |
T1416-IG-BOX-2943 | 2943 | 1 | 206 cm | 61 cm | 26 cm | 55 kg |
T1416-IG-BOX-2942 | 2942 | 1 | 200 cm | 80 cm | 17 cm | 43 kg |
The trampoline does not include materials to build an inground structure. The below manual is for the trampoline assembly only. For guides on how to build a trampoline inground read this information page

GeeTramp Force
The 14x16ft trampoline is the family social entertainer of trampolines. There isn’t another backyard trampoline in Australia that comes close to this one in size and quality; it is simply massive and robust in every way.
The 14x16ft trampoline is suited to various uses:
- Teenaged cheerleaders appreciate the enormous space for floor tumble practice, with space for several people to work out together on tumble and backwards walkover routines.
- Teenagers that need a safe space for soccer, wrestling, jumping, tricks and general energy burning (this is the one we had at home for our three teenage boys!)
The 14x16ft trampoline is ideal for a large family or a family with social and active teens, creating fond memories long into the future.
We find that the most experienced gymnasts typically prefer the 9x14ft or 10x17ft trampolines due to the extra jumping height obtained in these sizes when bouncing on your own.
Be assured this is a quality trampoline that will last like trampolines used to years ago.
The trampoline mat material is sourced from Tencate™ Permatron®, (Tencate is a USA based company). This is the most durable & UV resistant trampoline mat material available, all backed by our three-year warranty.
These pads are carefully hand-made and designed from the ground up with safety, durability, and long life in mind. Our pads feature a unique two-step foam that puts protection where you need it the most, (over the frame), also making it very water resistant - the water just runs off the pads and prevents excessive pooling.
Made from 60x2.5mm double hot-dipped galvanised steel. Our trampoline frame provides a very sturdy base for the springs and jumping mat and will also give the user a more responsive bounce.
Jumbo sized; this is the largest sized trampoline you can buy in Australia, It's a truly massive 14x16ft (4.3x4.9 meters) for kids (and parents) to jump and play.

We have designed this trampoline to be as easy as possible to assemble, however, due to the heavy duty components we recommend 2 or more people and allow 3-5 hours.

- Local landscaper
- Handyman
Note: We do not install In Ground trampolines.
- Local government requirements
- Soil type
- Retaining wall
- Drainage
- Getting the hole and retaining wall sizes right
Note: The trampoline frame sizes listed on our website are for naming the generic size of a trampoline and should be treated as a ballpark reference only, these nominal sizes should not be relied upon when digging the actual hole or for making the retaining wall. For our rectangle range, the long side rail bow’s out a little by design which needs to be factored in. Depending on the installation method you choose, you may also need to allow for an air flow gap. When sizing up to make the hole or retaining wall it is strongly suggested you already have the trampoline with the mat and springs assembled so you can then directly measure off the "actual" assembled product dimensions.
Technical | |
Maximum Weight Capacity | 150kg |
Frame | |
Frame Size (Imperial) | 14 x 16ft |
Frame Size (Metric) | 4267 x 4877mm |
Frame Height, Ground to Mat Height - F | 1067mm |
Frame Tube Size | 60 x 2.5mm |
Leg Tube Size | 60 x 2.5mm |
Leg Quantity | 4 |
Steel Tube Finish | Hot Dip Heavy Duty Galvanised, Inside & Out |
Mat | |
Mat Size | 3585 x 4190mm |
Mat Material | USA Tencate™ Permatron® Woven Polypropylene |
Spring | |
Spring Quantity - Per Side | 26 x 29 (+4 in corners) |
Spring Quantity - Total | 114 |
Spring Length | 260mm |
Pads | |
Spring Padding Cover | Forest Green, PVC 500D x .55mm thick for Upper & Lower Cover |
Spring Padding Insert | EPE Foam, 380mm wide, 50mm thick over the Frame, 25mm thick at the Mat edge |
